View detailsDouble-Shaft Shredder
Twin interlocking shafts shear bulky, tough waste into uniform small pieces efficiently.
What is a Double-Shaft Shredder?
The Double-shaft shredder is a widely used industrial shredder that efficiently processes various mixed waste materials, such as construction waste, industrial waste, and domestic waste. Depending on the material and final size, can equip it with different components or make it work with other stages of shredders to reduce the material to the required size.
Waste metal recycling industry, Building material stores, Household waste, Large waste treatment plants, Manufacturing plants, Restaurants, Farms, Government, Retail, Energy and mining, Construction engineering
Product Details of Double-Shaft Shredder
The shredder composed of motor, reducer, blade, shaft, frame, base, box, working platform.
The main equipment of the shredder adopts high-quality steel plate welding machining to ensure the stability.
The bearing seat adopts the patented split and is an easy to remove type, which can quickly.
The moving blade, fixed blade, bearing ,easy to maintain and replace the blade.
The double shaft independent drive is adopted, so that the materials are pressed accordingly during production to achieve the automatic feeding function.
The unique cutter shaft structure will not entangle the shaft or block.
The equipment in the production process of low speed and high torque, to improve the production efficiency.
Video Introduction of Double-Shaft Shredder
High-Efficiency Double-Shaft Shredder for Waste Recycling Centers
This high-efficiency double-shaft shredder is designed specifically for waste recycling centers. It uses two shafts with sharp blades to quickly shred large volumes of solid waste into uniform pieces, improving sorting efficiency, reducing waste volume, and supporting stable, heavy-duty operation in industrial recycling environments.
Key Components of a Double-Shaft Shredder
- Dual counter-rotating shafts & cutting blades – Core parts for shearing and shredding materials.
- Heavy-duty gearbox – Provides stable torque and drives the shafts.
- Electric motor – Supplies power for continuous operation.
- Rigid machine frame – Ensures stability and durability under heavy load.
- Control system – Manages operation, safety, and overload protection.
Characteristics of Double-Shaft Shredder
Dual-Shaft Shearing Action
Features two counter-rotating shafts equipped with interlocking blades （cutters） that perform a shear and compress action. This “chewing” mechanism easily handles tough, bulky, or rigid materials that single-shaft models cannot process.
High Torque & Low Speed Operation
Operates at low RPM with extremely high torque, prioritizing power over speed. This design prevents jamming when processing heavy loads （e.g., thick plastic, wood, metal） and ensures stable, continuous operation.
Robust & Modular Construction
Built with heavy-duty steel frames and wear-resistant alloy steel blades. The modular design allows for easy replacement of worn parts （blades, screens）and customization of cutting chambers to suit specific material sizes and output requirements.
Versatile Output Control
Utilizes a replaceable screen （grate） at the discharge end. The size of the screen holes determines the final particle size of the shredded material, offering flexibility from large chunks（pre-shredding） to smaller pieces （fine shredding）.
Working Principle of Double-Shaft Shredder
The double-shaft shredder operates through a twin-shaft, counter-rotating shearing process, designed to reduce large, tough materials into uniform sizes:
- Material Intake: Bulk materials（e.g., industrial waste, tires, wood）re fed into a hopper, often assisted by a hydraulic ram that pushes the material into the cutting chamber, preventing bridging.
- Shearing & Compression: Two parallel shafts fitted with interlocking, hook-shaped blades rotate at low speed（high torque）in opposite directions. The blades grab, compress, and shear the material between them, a process often described as “chewing.”
- Size Reduction & Screening: As material is broken down, it passes through a perforated screen（grate）at the bottom of the chamber. Only particles smaller than the screen holes exit the machine.
- Discharge: Shredded material falls through the screen onto a conveyor belt for collection or further processing（e.g., secondary shredding or baling）. The system includes safety sensors to reverse the shafts if a jam occurs, protecting the motor and gears.
Applications of Double-Shaft Shredder
Double-Shaft Shredder are versatile and used in various industries to improve waste sorting efficiency.
Common applications include:
- Solid Waste Management: Shreds MSW (Municipal Solid Waste), bulky waste, and industrial refuse for volume reduction and RDF production.
- Plastic & Rubber Recycling: Processes thick plastic pipes, large containers, car tires, and rubber products into uniform flakes for recycling.
- Wood & Green Waste: Reduces pallets, construction timber, and garden waste into biomass fuel or compost material.
- Hazardous & Sensitive Waste: Destroys chemical barrels, medical waste, and confidential documents safely with low dust and noise.
- E-Waste & Metal Processing: Pre-shreds electronic scrap, WEEE, and light metal scrap to facilitate downstream separation and recovery.
Benefits of Using Double-Shaft Shredder
Implementing Double-Shaft Shredder in waste sorting processes offers numerous benefits:
- Powerful Material Processing：Its twin-shaft, interlocking shear action easily handles tough, bulky, and contaminated materials (e.g., thick plastics, tires, MSW) that often jam single-shaft models.
- Stable & Safe Operation：Operates at high torque and low speed, minimizing vibration and noise. Most models include automatic reverse functionality to clear jams, protecting the motor and reducing downtime.
- Uniform Output Size：Equipped with a replaceable bottom screen that ensures the shredded material meets a consistent particle size, which is critical for efficient downstream processing (e.g., baling, recycling).
- High Throughput & Efficiency：The large feed hopper and continuous “chewing” action allow for high-volume processing. This significantly reduces waste volume (by up to 80%) and lowers subsequent handling and transportation costs.
Parameters of Double-Shaft Shredder
| Model | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 |
|---|---|---|---|---|---|---|---|
| Motor(kw) | 11*2 | 18.5*2 | 35*2 | 45*2 | 55*2 | 75*2 | 110*2 |
| Reducer | P6-P7 | P7-P8 | P8-P10 | P10-P12 | P11-P13 | P12-P16 | P14-P16 |
| Rotation Speed | 8-20rmp | 8-20rmp | 8-15rmp | 8-15rmp | 8-15rmp | 8-12rmp | 8-12rmp |
| Blades Diameter | 220-320 | 260-320 | 260-400 | 400-500 | 400-500 | 500 | 500 |
| Feeding Size | 1200*900mm | 1400*1000mm | 1600*1200mm | 1800*1300mm | 2000*1300mm | 2200*1700mm | 2400*2000mm |
| Weight(kg) | 1800 | 2500 | 3700 | 5500 | 7500 | 9500 | 13000 |
